Edge AI Computing

Intel® Core™ (14th gen) i9-14900T 24C/32T processor
Intel® Core™ (14th gen) i7-14700T 20C/28T processor
Intel® Core™ (14th gen) i5-14500T 14C/20T processor

R680E

2 x DDR5 SO-DIMM supports up to 5600 MT/s 96GB (ECC support with ECC DRAM)

Auto reset for unresponsive system (custom 1-255 sec/min settings in BIOS)

TPM 2.0

Processor Built-in GPU – Intel® UHD 700 Series Graphics
Optional Discrete GPU
・NVIDIA RTX™ Embedded 2000 Ada / 3500 Ada / 5000 Ada
・Intel Arc A370E

Without Discrete GPU : 2 x HDMI® with maximum resolution support of 3840 x 2160 @ 60Hz as specified in HDMI 2.0b
With Discrete GPU : Additional 2 x DP 1.4 (maximum resolution: 7680 x 4320 @ 60Hz)

1 x Line-out, 1 x Line-in, 1 x Mic-in

2 x 10GbE (Marvell AQC113) via RJ-45 (optional M12 X-code)
4 x 2.5GbE (Intel I226IT) via RJ-45 (optional PoE+ and M12 X-code)
** PoE supports 25.5W per port with total power budget: 120W

8 x USB 3.2 Gen 2

8 x DI (DC 9-60V), 8 x DO (DC 5V/100mA)

2 x RS-232/422/485

1 x M.2 2280 Key M for NVMe/SATA SSD
2 x M.2 2280 Key M for NVMe SSD
2 x front removeable tray for 2.5″ SATA SSD
* PCIe RAID and SATA RAID are supported by Intel® VMD and RST

1 x M.2 3042/3052 Key B for WWAN with dual SIM support
1 x M.2 2230 Key E for Wi-Fi/BT * Thermal solution is required for M.2 5G module

2 x Mini PCIe (full-size)

DC 9-60V input (nominal power input DC 12V/24V) via 5-pin terminal block

OCP, OVP, surge protection, reversed polarity protection

Ignition detection, Smart Power Management

Front removeable tray for RTC coin cell battery

Optional battery kit for up to 10 minutes emergency backup time (Battery charging Temp. 0°C~45°C and discharging Temp. -10°C~60°C)
* UPS backup time varies depending on actual overall system power consumption and battery is required to be charged before being used for system power backup
** Operating temperature will be limited within -10°C and 60°C with the battery kit installed.
Patent No.: M447854 (Built-in battery)

290 x 250 x 98 mm (11.42 x 9.84 x 3.86 in.)

5.70 kg (12.57 lb)

Aluminum Alloy

Wall

7 x SMA connector mounting hole

IP40

10% RH – 90% RH (non-condensing)

-40°C ~ 70°C (-40°F ~ 158°F) with 0.6 m/s airflow
* Operating temperature varies by accessories installed.

-40°C ~ 85°C (-40°F ~ 176°F)

IEC 60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
MIL-STD-810H, Method 514.8, Procedure I, Category 4

MIL-STD-810H, Method 516.8, Procedure I,
trucks and semi-trailers=15G (11ms)

CE, FCC Class A, UKCA, E-Mark, EN 50155, EN 45545-2 (R25)

Windows 11 IoT Enterprise LTSC

Ubuntu 22.04 LTS

ABOX-5221(P)(G)(-M12X)-zz (P= w/ PoE, G=w/ Discrete GPU, M12X=w/ M12 X code connectors,
zz=i7=i7-14700T, zz=i5=i5-14500T, zz=i3=i3-14100T

Intel® Core™ Processors (14th Gen) with Discrete GPU Options and High-Bandwidth 10GbE Edge AI Computer

Taiwan
